NVCxxT
The Nova NVC Vertical Clamp is designed for safe, upright lifting of steel plates and structural components. Featuring a spring-loaded cam and locking mechanism, it grips firmly during lifting and releases easily once the load is set down. With a durable, compact build and a large eye opening for shackle or hook attachment, this clamp is ideal for fabrication shops, yards, and job sites requiring vertical handling with confidence.
- ONE YEAR WARRANTY
- Economical
- All steel robust construction
- Heavy duty industrial plate clamp
- Latch locks in closed & opened positions, to easily position the clamp
- Eye hinge to allow pulling & lifting
- Sideways articulation
Models
Dimensions
| ||||||||||
| Cap. Tons | Dimensions in | |||||||||
| A | B | C | D | E | F | G | H | K | L | |
| 0.8 | 8.7 | 4.9 | 0.5 | 2.2 | 0.6 | 1.6 | 4.1 | 2.5 | 1.3 | 1.6 |
| 1 | 11.2 | 6.7 | 0.6 | 3.3 | 0.8 | 2.0 | 5.7 | 3.3 | 1.7 | 2.1 |
| 2 | 12.4 | 8.1 | 0.6 | 4.7 | 0.9 | 2.2 | 6.9 | 3.9 | 2.2 | 2.2 |
| 3 | 15.2 | 9.3 | 0.7 | 5.1 | 1.0 | 2.4 | 8.5 | 4.7 | 2.2 | 3.1 |
| 5 | 17.2 | 10.3 | 0.8 | 5.3 | 1.1 | 2.7 | 9.1 | 5.5 | 2.3 | 3.5 |
