Reference
wip-200-xxx
- Forged carbon steel, quenched & tempered
- 1/2T to 5T capacity
- 5:1 safery factor
Request a quote
Documentation
File
Descriptive document762.97 KB
Description
Sturdy
- Hook made of sturdy carbon steel
Sécuritaire
- Safety yellow finish
- Embossed working load limit (WLL)
Hi-durability latch
- High cycle, long life latch and spring
Dimensions
|
||||||||||||
| Model |
Capacity (TONS) |
Weight (Pounds) |
Dimensions (in) |
|||||||||
|
A |
B | C | D | E | F | G | H | I | J | |||
| WIP-200-0.5T |
0.5 |
0.38 |
1.32 | 0.62 | 0.35 | 0.75 | 0.53 | 0.76 | 2.55 | 0.75 | 3.83 | 2.75 |
| WIP-200-0.75T |
0.75 |
0.50 | 1.50 | 0.75 | 0.38 | 0.88 | 0.63 | 0.94 | 2.88 | 0.75 | 4.38 | 3.25 |
| WIP-200-01T |
1 |
0.80 | 1.75 | 0.88 | 0.44 | 1.00 | 0.69 | 1.06 | 3.13 | 0.81 | 4.88 | 3.63 |
| WIP-200-01.5T |
1.5 |
1.10 | 2.00 | 1.13 | 0.50 | 1.19 | 0.81 | 1.12 | 3.50 | 1.00 | 5.50 | 4.13 |
| WIP-200-02T |
2 |
1.70 | 2.38 | 1.25 | 0.59 | 1.38 | 0.94 | 1.22 | 3.94 | 1.19 | 6.31 | 4.56 |
| WIP-200-03T |
3 |
3.60 | 3.00 | 1.56 | 0.69 | 1.63 | 1.19 | 1.50 | 5.00 | 1.50 | 7.94 | 5.75 |
| WIP-200-05T | 5 |
7.00 |
3.81 | 2.00 | 0.88 | 2.06 | 1.50 | 1.88 | 6.25 | 1.75 | 10.00 | 7.38 |
